8 Channel Ampifier
AC Input Volt: AC115V or AC230V
Amplifier Type: Class-D
Fuse Rating: 10A
Quiescent Current @Vin=0: 0.15A
Power Auto On: YES
Auto On Input Sensitivity: < 15mVrms
Auto OFF Time Delay: >15Min
Mode : SE
Input Channel (STEREO): 8(4)
Output Channel (STEREO): 8(4)
Output Power THD1% 1KHz  RL=4 ohm: 40W/CH
Output Power THD1% 1KHz  RL=8 ohm: 25W/CH
Output Power Max RL=4 ohm: 50W/CH
Output Power Max RL=8 ohm: 30W/CH
Noise @Vin=0 : -65dB
Frequency (-3dB): 25Hz-20KHz
T.H.D@ Output Power 35W  RL=4ohm: 0.2%
Input Sensitivity @30W 1KHz  : 0.5Vrms
Load Impedance: 2-8 ohm
Short Circuit Protection: Yes
Mode : BTL
Input Channel: 4
Output Channel: 4
Output Power THD10% 1KHz RL=4 ohm : 140W/CH
Output Power THD10% 1KHz RL=8 ohm: 70W/CH
Output Power Max RL=4 ohm: 160W/CH
Output Power Max RL=8 ohm: 80W/CH
Noise @Vin=0: -55dB
Frequency (-6dB): 25Hz-20KHz
T.H.D @ Output Power 100W: 0.3%
Input Sensitivity @100W: 0.5Vrms
Load Impedance: 4-8 ohm
Dimensions: 480x350x100mm
